ENGLO Wet Extractors
ENGLO Dust Extractors are used worldwide for Mining, Power Utility and Heavy Process Industries. ENGLO specializes in the safe control of combustible dust and in fact The ENGLO Dust Extractor is considered to be one of the safest and most reliable dust extraction systems available on the market today.
LEARN MORE
Discover how ENGLO can revolutionize your dust collection strategy.
Download our Full Product Range Spec Sheet today to explore the capabilities of our complete range of dust collection solutions. Or click on the model in which you are interested in for more details below.
Product Range
Model 55
Volume: 110,000 - 128,000cfm
Motor Size: 350hp
Length: 192"
Width: 110"
Height: 97"
Water Use: 20-25gpm
Weight: ±27,500lbs
Model 52
Volume: 68,000 - 76,500cfm
Motor Size: 250 or 300hp
Length: 180"
Width: 92"
Height: 97"
Water Use: 23psi
Weight: ±17,200lbs
Model 46
Volume: 48,000 - 65,000cfm
Motor Size: 200 or 250hp
Length: 163"
Width: 76"
Height: 85"
Water Use: 13gpm
Weight: ±14,200lbs
Model 46P
Volume: 48,000 - 63,500cfm
Motor Size: 200 - 250hp
Length: 163
Width: 76"
Height: 85"
Water Use: 13gpm
Weight: ±14,200lbs
Model 36H
Volume: 27,000 - 40,500cfm
Motor Size: 200hp
Length: 144"
Width: 76"
Height: 85"
Water Use: 11gpm
Weight: ±13,350lbs
Model 36
Volume: 26,000 - 36,000cfm
Motor Size: 200hp
Length: 138"
Width: 60"
Height: 77"
Water Use: 11gpm
Weight: ±10,500lbs
Model 35
Volume: 19,000 - 32,220cfm
Motor Size: 125hp
Length: 138"
Width: 60"
Height: 77"
Water Use: 10gpm
Weight: ±10,100lbs
Model 33H
Volume: 14,500 - 23,500cfm
Motor Size: 75hp
Length: 129"
Width: 60"
Height: 70"
Water Use: 8gpm
Weight: ±10,000lbs
Model 33
Volume: 13,500 - 21,250cfm
Motor Size: 75hp
Length: 130"
Width: 40"
Height: 51"
Water Use: 8gpm
Weight: ±9,800lbs
Model 30
Volume: 9,800 - 15,400cfm
Motor Size: 75hp
Length: 83"
Width: 40"
Height: 51"
Water Use: 8gpm
Weight: ±5,000lbs
Model 27
Volume: 9,000 - 15,200cfm
Motor Size: 75hp
Length: 77.5"
Width: 37.4"
Height: 43"
Water Use: 7.5gpm
Weight: ±3,900lbs
Model 24P
Volume: 7,800 - 13,000cfm
Motor Size: 60hp
Length: 77.5"
Width: 37.5"
Height: 43.5"
Water Use: 7gpm
Weight: ±3,400lbs
Model 20
Volume: 5,000 - 7,000cfm
Motor Size: 20hp
Length: 89"
Width: 34"
Height: 29"
Water Use: 4 - 6gpm
Weight: ±2,200lbs
Model 18
Volume: 4,000 - 6,800cfm
Motor Size: 20hp
Length: 57.2"
Width: 30.5"
Height: 25.5"
Water Use: 6gpm
Weight: ±1,350lbs
Model 12
Volume: 1,000 - 1,550cfm
Motor Size: 3hp
Length: 44"
Width: 16"
Height: 23.5"
Water Use: 2gpm
Weight: ±350lbs
Gravity Water Separator
PRODUCT APPLICATIONS
Click Below for More Information.
Compact Versatile Design
Locate extractor close to dust source, minimize ducting length, and portability option.
Custom Designed Systems
Each system custom designed for customers needs.
Lower Cost
Lower capital, installation and operating cost than conventional dry collectors.
Portability
Dust Extractor Units can be fixed mounted, equipment, skid or trailer mounted depending on the application needs.
Highly Trained Service & Support
Full service and support team dedicated to providing “Best in the Industry” assistance.
According to the Environmental Protection Agency Part II 40 CFR 60 Standards of Performance for Coal Preparation and Possessing Plants; Proposed Rule, ENGLO is considered Best Demonstrated Technology (BDT), and has a lower cost than conventional dry collection systems. ENGLO Dust Extraction and its highly experienced team have met the challenges set forth by MSHA, OSHA and the EPA to address the needs of its customers to better manage fugitive combustible dust.
Each ENGLO Dust Extractor comes complete with motor, fan, demisters, extraction panel scrubber box, manual valve on main water supply and backflush, pressure gauge (psi or bar), pressure regulator and hose assembly for front sprays. The Internal and External housing is coated with two-part epoxy. Demisters are galvanized and the extraction panel is constructed of stainless steel. Motor is available as standard four- pole (1780rpm) TEFC or U/L XP. A water automation package is recommended for plant installations. Noise reduction system is available.
ENGLO modular approach tailors the equipment to the application with adaptable “Modules” on the inlet and outlet of the ENGLO unit to adapt to dust loading requirements and efficiency objectives.
